KTFH-12 Thyristor solid state switch equipment
OVerview
KTFH-12 thyristor solid-state switch equipment, using solid-state switch switching technology and advanced control technology, switching time in milliseconds, this equipment is mainly used in 12kV dual-circuit power supply system, in the case of one power supply disconnection or loss of voltage, fast Switch to another power supply to ensure continuous operation of the load and avoid losses to the enterprise due to power failure and shutdown of the equipment
Features
◆Fast switching speed
◆Phase frequency detection function
◆Voltage sag detection
◆Manual/automaticswitch
◆Fault waveform record
◆Compact and naturally cooled thyristor valve body
◆Emergency protection function
Note: The user can negotiate with our company when the above-mentioned normal use conditions are exceeded.
Conditions of Use
◆Altitude: not more than 2000 meters
◆Temperature:-5～45℃
◆Humidity: The relative humidity at 25℃ is not higher than 80%
◆Place of use: The equipment works with no pollution or only dry, non-conductive pollution
Technical Parameters
|
Item |
Parameter |
|
|
Rated voltage (kV) |
12 |
|
|
Voltage fluctuation range |
-20%~+10% |
|
|
Rated frequency (Hz) |
50±1.25 |
|
|
Rated current (A) |
630 |
Rated current is designed according to customer needs |
|
1250 |
||
|
Switching time(s) |
0.02-0.045 |
|
|
Rated short-time withstand current |
0.1s,8kA |
|
|
Rated peak withstand current |
0.01s,20kA |
|
|
Rated insulation level (kV) |
Equipment 1min power frequency withstand voltage phase to phase/to ground |
42/42 |
|
SCR valve body 1min power frequency withstand voltage valve section to ground/ between valve sections |
42/18 |
|
